Excel Enbeam OM3 Multimode Fibre Optic Cable Loose Tube 24 Core 50/125 Dca Black
Excel OM3 50/125 μm loose tube optical fibre cables have been designed specifically for internal and external applications. These compact, lightweight cables are extremely flexible and are quick and easy to install. The cables are constructed around a gel filled (non‐dripping and silicon free) tube containing up to 24 colour coded 250 μm primary coated fibres. This tube is covered with an E-Glass strength member.
_1600px.jpg)
Key features
Duct grade rodent resistant
Cut to length service
Sequentially metre marked
25 Year system warranty
Euroclass Dca-s2-d2-a1
compatibility:
CIBSE TM65 Embodied Carbon: 0.190 kg CO2e
Number of Cores
24
Type of tube
Loose tube
Number of fibres per tube
24
Fibre type
Multi mode 50/125
Category
OM3
Rodent resistant
yes
Outer sheath material
Copolymer, thermoplastic (LS0H)
Outer sheath colour
Black
Flame retardant according to IEC 60332-1-2
yes
Low smoke (acc. IEC 61034-2)
yes
Reaction-to-fire class according to EN 13501-6
Dca
Smoke development class according to EN 13501-6
s2
Euro class flaming droplets/particles according to EN 13501-6
d2
Euro class acidity according to EN 13501-6
a1
Outer diameter approx.
6.5 mm
