Environ Data Centre (DCR) Racks

Solid and Adjustable, by design.

Up to 1500kg Load Bearing

Range of Heights, Widths and Depths

High Ventilation (80%) on Front and Double Rear Door

Enhanced Airflow

25-Year Warranty

The Environ DCR Range of Data Centre Racks is a new design and includes numerous features and benefits which make them ideal for a data centre environment, delivering flexibility and quality.

Based on Excel's successful, market-accepted Environ Rack design, the DCR racks feature the same flexibility of options and configuration with higher airflow mesh doors, airflow management baffles at the front, finger style cable management and upgraded manual or optional electronic handles. There is also improved cable access with full depth wide brush strips on the roof, cabinet to cabinet cable routing via side brush openings and multiple brush entry through the airflow management baffles.

When installed by an Excel partner as part of a total Excel installation, they are covered by the 25-year warranty.

Why Choose Excel Environ DCR Racks?

Front to back cable brush strips to provide large cable entry/exit points - including 16A/32A commando style plugs

Top mount roof raceway available for cable management, with add-ons available to bridge gaps between racks

Baffle top plate completes airflow management at the front

Overlapping brush strips on top and bottom side panels to facilitate cable routing between racks

Airflow management baffles fitted as standard around the front profiles

Optional blanking plates available as 4U, breakable into 1U pieces

Base has several configurable blanking panels and side brush strips to allow for cable entry/exit or blanking

Finger cable management fitted at the front in line with profiles

Three-point locking on rear doors using mechanical rods and cam

Positioning castors with locking and adjustable jacking feet included as standard

Cable management trays mounted at both sides at the rear, featuring multiple cutouts for cable routing and PDU mounting

Excel Encyclopaedia

Further information about Excel’s Environ Racks can be found online in the Excel Encyclopaedia. The Excel Encyclopaedia is a comprehensive document that aims to educate installers, designers and consultants about structured cabling as well as providing details about the complete Excel range. It also includes useful documents such as tender responses, white papers and much more.

See for yourself

Our Environ Racks are available to view, fully equipped and installed, in our Demonstration Facilities in Birmingham, London and Dubai.
